Processing example of Injection mold parts
Plastic mold parts
|
Material |
DC53 |
| Hardness | HRC60～62 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Plastic mold parts
|
Material |
HPM31 |
| Hardness | HRC56～58 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Plastic mold parts
|
Material |
SUS630 |
| Hardness | HRC60～62 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Medical plastic mold |
Plastic mold parts
|
Material |
S-STAR |
| Hardness | HRC60～62 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Plastic mold parts
|
Material |
HPM31 |
| Hardness | HRC58～60 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Plastic mold parts
|
Material |
HPM38 |
| Hardness | HRC60～62 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Plastic mold parts
|
Material |
DC53 |
| Hardness | HRC60～62 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Plastic mold parts
|
Material |
PD613 |
| Hardness | HRC58～60 |
| Precision |
±0.002mm |
| Finish |
Ra0.1μm |
| Mold category |
Automotive connector |
Processing example of Press mold parts
Punch parts
|
Material |
EF10 |
| Hardness | HRA92～ |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.08μm |
Punch parts
|
Material |
Ceramics |
| Hardness | HRA92～ |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.08μm |
Press mold plate
|
Material |
SLD |
| Hardness | HRC60～ |
| Precision |
±0.005mm |
| Flatness |
±0.005mm |
| Finish | Ra0.1μm |
Press mold base
|
Material |
S45C,A7075 |
| Hardness | HRC50～52 |
| Precision |
±0.01mm |
| Flatness |
±0.005mm |
| Finish |
Ra0.2μm |
Processing example of Package mold parts
Cavity insert
|
Material |
ZDP4 |
| Hardness | HRC62~ |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Pot/Plunger Parts
|
Material |
W.C |
| Hardness | HRA92～ |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.02μm |
Cavity Block Parts
|
Material |
ASP23 |
| Hardness | HRC63～65 |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Cavity Block Parts
|
Material |
ASP23 |
| Hardness | HRC63～65 |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Cavity Block Parts
|
Material |
ASP23 |
| Hardness | HRC63～65 |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Cavity Block Parts
|
Material |
ASP23 |
| Hardness | HRC63～65 |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Cutting Die Parts
|
Material |
W.C |
| Hardness | HRA92~ |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Cutting Die Parts
|
Material |
HAP40 |
| Hardness | HRC63～65 |
| Precision |
±0.002mm |
| Flatness |
±0.001mm |
| Finish |
Ra0.1μm |
Examples of machining of mechanical parts
Optical, Electronic parts
|
Material |
A7075/A6061 |
| Hardness | ～ |
| Precision |
±0.01mm |
| Finish |
Ra0.2μm |
| Application area | Optical, electronic related parts |
Medical instrument parts
|
Material |
A7075/A6061 |
| Hardness | ～ |
| Precision |
±0.01mm |
| Finish |
Ra0.2μm |
| Application area |
Medical equipment parts processing |
Semiconductor parts
|
Material |
A7075/A6061 |
| Hardness | ～ |
| Precision |
±0.01mm |
| Finish |
Ra0.2μm |
| Application area | Semiconductor equipment parts |
Turbine parts
|
Material |
S136, TC4 |
| Hardness | ～ |
| Precision |
±0.01mm |
| Finish |
Ra0.2μm |
| Application area | Mechanical related parts |
Vibrating disk parts
|
Material |
A7075,SUS304 |
| Hardness | ～ |
| Precision |
±0.01mm |
| Finish |
Ra0.2μm |
| Application area | Automation equipment parts |
Cam parts
|
Material |
DC53 |
| Hardness | HRC58～60 |
| Precision |
±0.005mm |
| Finish |
Ra0.1μm |
| Application area | Automation equipment parts |
Mechanical automation parts
|
Material |
S45C,S50C,SKS3,SKD11 |
| Hardness | HRC45～60 |
| Precision |
±0.005mm |
| Finish |
Ra0.1μm |
| Application area | Automation equipment parts |
Mechanical automation parts
|
Material |
S45C,SKS3,SKD11,S50C |
| Hardness | HRC45～60 |
| Precision |
±0.005 |
| Finish |
Ra0.1μm |
| Application area | Automation equipment parts |
Box parts for new energy vehicle chargers
|
Material |
ADC12,ADC14 |
| Hardness | ~ |
| Precision |
±0.05 |
| Finish |
Ra0.3μm |
| Application area | New energy automobile |
Box parts integrated in the CDU system
|
Material |
ADC12,ADC14 |
| Hardness | ~ |
| Precision |
±0.05 |
| Finish |
Ra0.3μm |
|
Application area |
New energy automobile |
Box parts of hydrogen fuel cell stack
|
Material |
ADC12,ADC14 |
| Hardness | ~ |
| Precision |
±0.05 |
| Finish |
Ra0.3μm |
|
Application area |
New energy automobile |
Box parts for new energy DC/DC converters
|
Material |
ADC12,ADC14 |
| Hardness | ~ |
| Precision |
±0.05 |
| Finish |
Ra0.3μm |
|
Application area |
New energy automobile |
